3-Channel, Low-Leakage ESD Protector
ABSOLUTE MAXIMUM RATINGS
(Voltages referenced to GND.)
V CC to GND...........................................................-0.3V to +18V
I/O-1, I/O-2, I/O-3 to GND ........................ -0.3V to (V CC + 0.3V)
Continuous Power Dissipation (T A = +70 N C)
5-Pin SC70 (derate 3.1mW/ N C above +70 N C) .........246.9mW
Operating Temperature Range ........................ -40 N C to +125 N C
Storage Temperature Range............................ -65 N C to +150 N C
Junction Temperature .....................................................+150 N C
Lead Temperature (soldering, 10s) ................................+300 N C
Thermal Resistance (Note 1)
B JA .............................................................................324 N C/W
B JC ............................................................................115 N C/W
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-
layer board. For detailed information on package thermal considerations, refer to www.maxim-ic.com/thermal-tutorial .
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these
or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may
affect device reliability.
ELECTRICAL CHARACTERISTICS
(V CC = +5V, T A = T MIN to T MAX , unless otherwise noted. Typical values are at T A = +25 N C.) (Note 2)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
Supply Current
V CC
I CC
0.9
1
16
100
V
nA
Diode Forward Voltage
V F
I F = 10mA, T A = +25° C
T A = +25°C, ±15kV
Human Body Model,
Positive transients
0.65
0.95
V CC +
25
V
V
I F = 10A
Negative transients
-25
Channel Clamp Voltage
(Note 3)
V C
T A = +25°C, ±8kV
Contact Discharge
(IEC 61000-4-2),
I F = 24A
T A = +25°C, ±15kV
Air-Gap Discharge
(IEC 61000-4-2),
I F = 45A
Positive transients
Negative transients
Positive transients
Negative transients
V CC +
60
-60
V CC +
100
-100
V
V
V
Channel Leakage Current
(Note 4)
I/O Capacitance
T A = -40°C to +50°C
T A = -40°C to +125°C
Bias of V CC /2, f = 1MHz (Note 4)
-1
-1
6
+1
+1
7
nA
μA
pF
ESD PROTECTION
Human Body Model
IEC 61000-4-2 Air-Gap
Discharge
IEC 61000-4-2 Contact
Discharge
±15
±15
±8
kV
kV
kV
Note 2: Parameters are 100% production tested at TA = +25°C. Specifications over temperature guaranteed by design only.
Note 3: Idealized clamp voltages. See the Applications Information section for more information.
Note 4: Guaranteed by design, not production tested.
2
______________________________________________________________________________________
